A customer involved in research in the life science field asked us about a workstation for single particle analysis using a cryo-electron microscope. We would like to find the optimal configuration with a budget of around 220 million yen. The specific conditions are as follows.
| Your desired conditions | |
| CPU | A product that has as many cores as possible and can perform high-speed processing. |
| memory | 256GB |
| storage | 1TB SSD for system, 2TB M.4 NVMe SSD for temporary storage, 10TB HDD for data |
| Video card | Geforce RTX4090 x2 |
| power environment | I want to operate in a 100V environment Please let me know if the configuration with the above conditions does not support a 100V environment. |
Based on customer requests, we proposed the following configuration.
| CPU | AMD Ryzen ThreadripperPRO 7965WX (4.20GHz 24 cores) |
| memory | 256GB ECC REG |
| Storage 1 | 1TB SSD S-ATA |
| Storage 2 | 4TB SSD M.2 NVMe Gen4 |
| Storage 3 | 16TB HDD S-ATA |
| video | NVIDIA Geforce RTX4090 24GB x2 |
| network | on board (1GbE x1 10GBase-T x1) |
| Housing + power supply | Tower type housing + 1600W |
| OS | None |
Powered by the latest Ryzen Threadripper PRO 7000 WX series
This configuration uses the 2024-core model of the Ryzen Threadripper PRO 4 WX series, which is the latest as of April 7000.
With 24 cores and a 4.20GHz operating clock, you can expect high performance during analysis.
NVIDIA Geforce RTX4090 x2200V environment is required when installing
In accordance with your specifications, NVIDIA Geforce RTX4090 x2 is installed.
In addition, the TDP of NVIDIA Geforce RTX4090 is 450W, which is a product with high power consumption, so if two cards are installed, a 2V environment is required.
If being able to use it in a 100V environment is a priority, you can reduce the number of RTX4090 installed to one, or change to two video cards with lower power consumption such as NVIDIA A1 or NVIDIA RTX6000 Ada. We can accommodate you.
Software can also be pre-installed
If you wish, we can also pre-install software for cryo-electron microscopy.
Please feel free to contact us if you wish.
The configuration of this case study is based on the conditions given by the customer.
We will flexibly propose machines according to your conditions, so please feel free to contact us even if you are considering different conditions than what is listed.
|
